| Model |
| Brand |
ViewSonic |
| Model |
VA1912wb |
| Cabinet Color |
Black |
| Display |
| Panel |
Active Matrix, TFT LCD |
| Screen Size |
19" |
| Widescreen |
Yes |
| Display Type |
WXGA+ |
| Maximum Resolution |
1440x900 |
| Recommended Resolution |
1440x900 |
| Viewing Angle |
160°(H) / 160°(V) |
| Pixel Pitch |
0.285mm |
| Brightness |
280 cd/m2 |
| Contrast Ratio |
700:1 |
| Response Time |
5ms |
| Horizontal Refresh Rate |
30~82kHz |
| Vertical Refresh Rate |
50~85Hz |
| Connectivity |
| Input Video Compatibility |
RGB analog (75 ohms, 0.7/1.0 Vp-p)
Digital (TMDS, 100 ohms) |
| Connectors |
15-pin mini D-sub, DVI-D |
| D-Sub |
1 |
| DVI |
1 |
| HDMI |
No |
| Power |
| Complies with |
Meets TCO'03 and ENERGY STAR standards |
| Power Supply |
AC 100-240V, 50/60Hz |
| Power Consumption |
32W (typ) |
| Convenience |
| User Controls |
Basic: Power, 1, down, up, 2
OnView: Auto image adjust, contrast, brightness, input select, audio adjust, ViewMatch color adjust (sRGB, 9300K, 6500K-default, 5400K, user color RGB), information (resolution, H. frequency, V. frequency, pixel clock, model number, serial number, web site), manual image adjust (H. size, H. position, V. position, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall |
| Regulatory Approvals |
UL, cUL, FCC-B, CB, CE, NOM, TUV/Ergo, ICES-003, Argentina TUV/S, TUV/GS, (covers ISO 13406-2), TCO'03, GOST-R, SASO, PCBC, TUV-S, BSMI, CCC, ENERGY STAR, PSB, C-TICK, RoHS |
| Adjustable Stand |
Tilt Adjustments |
| Built in TV Tuner |
No |
| Built in Speakers |
Dual integrated stereo speakers |
| Features |
•ClearMotiv technology: Fast 5ms video response enables digital HD-quality full motion video.
•Dynamic Structure: Innovative liquid crystal composition and pixel matrix accelerate video response for seamless video and intense graphics.
•OSD/power lock secures your settings: Prevents changes to monitor settings and maintains an optimized image.
•Stylish slim-bezel design
•OnView controls for superior screen adjustability
•Integrated power supply
•PC and Mac compatible
•TCO'03 and ENERGY STAR qualified |
| Dimensions |
| Dimensions (W×H×D) |
17.8" x 15.4" x 7.8" |
| Weight |
9.9 lbs. |
| Temperature Range |
32-104°F (0-40°C) |
| Humidity Range |
10-90% (no condensing) |
