Model

Brand

GIGABYTE

Model

GA-M51GM-S2G

Supported CPU

CPU Socket Type

Socket AM2

CPU Type

Athlon 64 X2/Athlon 64 FX/Athlon 64

FSB

1000MHz Hyper Transport (2000 MT/s)

Chipsets

North Bridge

NVIDIA GeForce 6100

South Bridge

NVIDIA nForce 430

Memory

Number of DDR2 Slots

4x 240pin DDR2

DDR2 Standard

DDR2 800

Maximum Memory Supported

4GB

Dual Channel Supported

Yes

Expansion Slots

AGP Slots

None

PCI Express x16

1

PCI Express x1

1

PCI Slots

2

Storage Devices

PATA

2 x ATA100 up to 4 Devices

SATA 3Gb/s

4

SATA RAID

RAID 0/1/0+1/5

Onboard Video

Onboard Video

Yes

Onboard Video Chipset

NVIDIA GeForce 6100

Onboard Audio

Audio Chipset

Realtek ALC883

Audio Channels

8 Channels

Onboard LAN

LAN Chipset

Marvell 88E1116

Max LAN Speed

10/100/1000Mbps

Rear Panel Ports

PS/2

2

COM

1

LPT

1

VGA

1

USB

4x USB 2.0

IEEE 1394

1x 1394a

Audio Ports

6 Ports

Onboard USB

Onboard USB

4x USB 2.0

Onboard 1394

Onboard 1394

2x 1394a

Physical Spec

Form Factor

Micro ATX

Dimensions

9.6" x 9.6"

Features

Power Pin

24 Pin

Features

RoHS compliant motherboard for green computing
